P_G_0064_SW
A.
B.
CLICK
Fig. 9
Suggested bolts and washers for fixing the assembly foot
Bolt Type Size Washer
DELTA-PT bolt 50 (WN5412/5452) A5.3 (DIN 125)
PT bolt 50 (WN1441/1411 KA/B) -
Flat-head bolt M5 (DIN EN ISO 7045) A5.3 (DIN 125)
Allen bolt/ M5 (DIN EN ISO 4762) A5.3 (DIN 125)
Assembly
