6.3 Disconnection of the Fire Brigade Panel (FBP) Connections
If the 6100 is equipped with the optional Fire Brigade Panel control interface ensure that the ribbon
cable and earthing cable are disconnected from the rear of the controller as shown in figure 6.1.
Figure 6.1 Removing the FBP control interface connections
