7.22 Editing Device Location Text
The Edit Device Text menu allows the user to enter 20 characters of text for any loop device on the
6100.
1. Enter the user code supplied with the system and press the
¿
key to access the menus.
2. Using the ◄ and ► keys navigate to the EDIT DEVICE TEXT menu and press
¿
.
3. Using the ◄ and ► keys navigate to the device address that you wish to edit the text on and
press the ▲ or ▼ to enter editing mode ( Figure 7.14 ).
4. Using the ◄ and ► keys navigate through the text characters then ( the character being edited
has a ^ positioned underneath it ), then using the ▲ and ▼ keys, edit the character as required.
5. Press the
¿
key to accept the changes and return to the main menu.
Figure 7.14 – Edit Device Text display
7.23 Editing Zone Text
The Edit Zone Text menu allows the user to enter 20 characters of text for each of the 32 zones
available on the 6100.
1. Enter the user code supplied with the system and press the
¿
key to access the menus.
2. Using the ◄ and ► keys navigate to the EDIT ZONE TEXT menu and press
¿
.
3. Using the ◄ and ► keys navigate to the zone that you wish to edit the text on and press the ▲
or ▼ to enter editing mode ( Figure 7.15 ).
4. Using the ◄ and ► keys navigate through the text characters then ( the character being edited
has a ^ positioned underneath it ), then using the ▲ and ▼ keys, edit the character as required
5. Press the
¿
key to accept the changes and return to the main menu.
Figure 7.15 – Editing Zone Text display
ZONE 28
ZONE TEXT FOR ZONE 28
^ . . . . . . . . . . . . . . . . . .
Address 001 optical
Device text addRESS 1
^ . . . . . . . . . . . . . . . . . .
