Appendix 4 6100 Event Descriptions
DEVICE IN ALARM
The loop device at the address shown has entered the alarm state.
DEVICE FAULT
The loop device at the address shown has entered the fault state. It may no longer be operating correctly
and must be investigated immediately.
DEVICE FAILED SETUP
The loop device at the address shown has failed to setup correctly when the system initialised. The device
will not detect fires. The system must be restarted, or the device must be removed for 30 seconds, then
replaced to attempt to rectify the fault.
DEVICE PREALARM
The loop device at the address shown has detected a level of smoke, heat or carbon monoxide that is
indicative of a fire but not quite at the fire threshold. To view devices in pre-alarm, use the 'View Faults'
menu.
DEVICE DISABLED
The device at the address shown has been disabled. Activations from this device will not generate an alarm.
If the device develops a fault, the fault will not be registered on the 6100. Disabled output devices will still
activate.
DEVICE INVISIBLE SW
A device, at the address shown, programmed as class ‘Invisible Switch’ has activated.
CONT OPGRPS DISABLED
A loop device programmed to disable control output groups has operated, and output devices programmed
into control type output groups will not have been able to activate.
OPGROUP 31 DISABLED
A loop device programmed to disable output group 31 has operated, and output devices programmed into
output group 31 will not have been able to activate.
OPGROUP 32 DISABLED
A loop device programmed to disable output group 32 has operated, and output devices programmed into
output group 32 will not have been able to activate.
ZONE IN TEST
The zone shown has been programmed into walk test mode.
ZONE DISABLEMENT
The zone shown has been disabled. Activations from devices in this zone will not generate an alarm. If
devices in this zone develop a fault, the fault will not be registered on the 6100. Disabled output devices will
still activate.
ZONE FAULT
One, or more, loop devices in this zone have developed a fault.
ALARM FAULT
A fault has been detected with an alarm output device on the loop, or a fault has been detected on one or
both of the conventional alarm outputs.
ALARMS DISABLED
The alarm outputs have been disabled. Alarm outputs from loop devices, or connected to the conventional
alarm outputs will not activate.
FIRE LINK FAULT
A fault has been detected on the fire link output. The fire link may not operate when the 6100 detects a fire.
