Protec 6100 - Appendix 3: Quick Reference Guide; Accessing Levels and Basic Operations; Panel Reset, Testing, and Settings

N93-572-88 Issue 12 NH Page 33 of 52 © Protec Fire Detection plc 2020
With reference to figure 7.4
To set the input group for the address
Use the ▲ and ▼ keys to select INPUT GROUP field.
Use the ◄ or ► keys to set the input group number for the address. Refer to section 7.2 for input
group ranges.
To set the output group for the address
Use the ▲ and ▼ keys to select OUTPUT GROUP field.
Use the ◄ or ► keys to set the output group number for the address, valid output group numbers are
1 to 32 inclusive.
To set the volume level for the address
Use the ▲ and ▼ keys to select VOLUME field.
Use the ◄ or ► keys to set the required volume level for the loop sounder. Valid levels are LOW, MED
and HIGH.
Figure 7.4 Program address screen 2
With reference to figure 7.5
To set the DAY and NIGHT sensitivities for the address
Use the ▲ and ▼ keys to select the DAY SENSE, or NIGHT SENSE field as required.
Use the ◄ or ► keys to set the required sensitivity level for the address. Refer to section 7.6 for input
group ranges.
To set the CLASS data for the address
Use the ▲ and ▼ keys to select CLASS field.
Use the ◄ or ► keys to set the class for the address.
Figure 7.5 Program address screen 3
Press the
¿
key at any time to store any changes, the 6100 will warn that changes are to be made to
the site data and the panel will reset and reboot as shown in figure 7.6.
Figure 7.6 Program address warning display
Press the
¿
key to accept, or the ◄, ►, ▲ or ▼ keys to decline and remain in the menu. Then, if
possible, upload and save the site file on a PC.
Address 001 Opt Ht
Input group 01
Output group 01
Volume High
Address 001 Opt Ht
Day sense bedroom
Night sense office
class automatic
Warning
Panel will reset and
update site data
continue ?
