Protek 3201 User Manual

▲▼
① SPECTRUM
② BAR 160CH
③BAR 80CH
④BAR 40CH
⑤BAR 20CH
⑥BAR 10CH
⑦BAR 5CH
⑧ DIFFEREN
⑨SINGLE
⑩ COUNTER
▲▼
① SPECTRUM
② BAR 160CH
③BAR 80CH
④BAR 40CH
⑤BAR 20CH
⑥BAR 10CH
⑦BAR 5CH
⑧ DIFFEREN
⑨SINGLE
⑩ COUNTER
FUNCTION (Display)
▶ Scans 160 Channels and displays their signal levels as a spectrum. The
channel at the marker indicator will have its frequency and amplitude
displayed on the LCD. See figure 1 on page 25.
▶ Scans 160 Channels and displays their signal levels as bar graphs. The
channel at the marker indicator will have its frequency and amplitude
displayed on the LCD. See figure 2 on page 25.
▶ Scans 80 Channels and displays their signal levels as bar graphs. The
channel at the marker indicator will have its amplitude and frequency
displayed on the LCD. See figure 3 on page 25.
▶ Scans 40 Channels and displays their signal levels as bar graphs. The
channel at the marker indicator will have its amplitude and frequency
displayed on the LCD. See figure 4 on page 25.
▶ Scans 20 Channels and displays their signal levels as bar graphs. The
channel at the marker indicator will have its amplitude and frequency
displayed on the LCD. See figure 5 on page 25.
▶ Scans 10 Channels and displays their signal levels as bar graphs. The
channel at the marker indicator will have its amplitude and frequency
displayed on the LCD. See figure 6 on page 25.
▶ Scans 5 Channels and displays their signal levels as bar graphs. The
channel at the marker indicator will have its amplitude and frequency
displayed on the LCD. See figure 7 on page 25.
▶ Scans and displays 2 signal levels in which one frequency is entered
from the keyboard and the other signal level is at difference frequency
selected from the step frequency menu. The amplitude of each is
displayed as a bar graph along with their difference amplitude. See
Figure 8 on page 25.
▶ Displays a single frequency and its amplitude as a bar graph. See figure 9
on page 25.
▶ Displays a measured frequency together with its amplitude as a bar graph
see figure 10 on page 25.
24
