3. Scan modes
Selects the manner in which signal levels are scanned and displayed on the LCD.
There are three scan modes to choose from, Search, Manual and Channel scan.
Press the following key sequence to display the scan mode menu:
(select the Scan menu) (select the desired scan mode) See below
MENU ENTER ENTER
Manual Scan: (Menu Scan)
A signal level frequency is entered from the keyboard
And is displayed as the center frequency.
The frequency span is set by a frequency selected form
The step frequency Menu.
Channel Scan: (CH Scan)
Names and frequencies of signal levels of interest may
Be entered and stored in the channel memory prior to
Scanning. When scanned these signal levels will be
Displayed along with their frequencies and name.
Search Scan: (search)
Scans and displays signal levels between a start and
Stop frequency. The start and stop frequencies are
Entered from the keyboard and are displayed on the
LCD
26
26
