Proton Products SL mini and SLR mini Series Speed and Length Gauges Instruction Manual - issue 1s
3
Configure the DeviceNet interface as required and click the “Exit” button when complete:
Label
Value
Description
DEV ID
0 ~ 125
Enter the DeviceNet ID (address) assigned to the gauge.
DEV Baud Rate
125K
Enter the DeviceNet baud rate.
250K
500K
Configuration via input parameters:
This interface may be configured by writing to the following input parameters:
Input parameters:
DW
Bit
Comment
Unit
Range/Remark
Default
46
DeviceNet address
0~63
7
47
DeviceNet baud rate
0=125K
1=250K
2=500K
