Proxim Tsunami MP.11 2454-R User Manual

Technical Specifications MP.11-R Installation and Management
Integrated Antenna Specifications
218
Model 4954-R Subscriber Unit with Integrated 21-dBi Antenna
Model 5054-R/5054-R-LR Subscriber Unit with Integrated 23-dBi Antenna
VSWR 1.5 : 1 Max
Feature Specification
Part Number 4954-SUR-xx
Frequency range 4900 - 5100 MHz
Nominal Impedance 50 ohms
Gain 21 dBi
Front-to-Back Ratio 35 dB
HPBW/vertical 10 degrees
HPBW/horizontal 10 degrees
Cross Polarization 22 dB
Power handling 1 W (cw)
VSWR 1.5: 1 Max
Feature Specification
Part Number 5054-SUR-xx
Frequency range 5250 - 5875 MHz
Nominal Impedance 50 ohms
Gain 23 dBi
Front-to-Back Ratio 35 dB
HPBW/vertical 9 degrees
HPBW/horizontal 9 degrees
Cross Polarization 23 dB
Power handling 1 W (cw)
VSWR 2.0: 1 Max
Feature Specification

Proxim Tsunami MP.11 2454-R Specifications

General

Brand	Proxim
Model	Tsunami MP.11 2454-R
Category	Wireless Router
Language	English
