Technical Specifications MP.11-R Installation and Management
Range Information
224
Range Information
Model 2454-R
NOTE: Minimum fade margin; 99.995% or better availability; average terrain/climate; no unusual mulitpath; proper path
clearance (0.6F1). Note that these calculations are done using 17 dBi antenna gain.
6
Model 4954-R
NOTE: Note that these calculations are done using 21 dBi antenna gain.
Model 5054-R
NOTE: Minimum fade margin; 99.995% or better availability; average terrain/climate; no unusual mulitpath; proper path
clearance (0.6F1). Distance calculations for 5 MHz and 10 MHz are comparable for ETSI regulatory domains.
Proper TPC settings (-9 dB @ 20 MHz, -12 dB @ 10 MHz, -15 dB @ 5 MHz) should be set to meet power density
rules. Increased distances are possible in the US with proper engineering. Note that these calculations are done
using 23 dBi antenna gain.
NOTE:
Model 5054-R-LR
NOTE: Ranges calculated with a minimum of 15 dB theoretical system operating margin with a 20 MHz bandwidth.
Assumes the integrated 28 dBi external antenna (Russia) is used at each end, the link has clear line of site,
proper path clearance (0.6F1), average terrain/climate, and no unusual multipath. US values presume transmit
power is reduced to -3 dBm to comply with FCC EIRP limitations. ETSI values presume transmit power is
reduced to 7 dBm to comply with ETSI EIRP limitations. Note that these calculations are done using 23 dBi
antenna gain. For Russia, these calculations are done using 28 dBi antenna gain.
Frequency 54 Mbps 36 Mbps 6 Mbps
2.4-2.4835 GHz (US) 1.5 mi/2.4 km 3.7 mi/5.9 km 10.9 mi/17.4 km
2.4-2.4835 GHz (ETSI) 0.4 mi/0.6 km 1.2 mi/1.9 km 3.4 mi/5.4 km
Frequency 54 Mbps 36 Mbps 6 Mbps
4.940-4.990 GHz 1.5 mi/2.4 km 3.0 mi/4.8 km 7.5 mi/12.0 km
Frequency 54 Mbps 36 Mbps 6 Mbps
5.250-5.350 GHz (US) 1.1 mi/1.8 km 2.4 mi/3.8 km 5.2 mi/8.3 km
5.470-5.725 GHz (US&ETSI) 1.0 mi/1.6 km 2.4 mi/3.8 km 5.3 mi/8.5 km
5.725-5.850 GHz (US) 1.6 mi/2.6 km 3.5 mi/5.6 km 9.7 mi/15.5 km
Frequency 54 Mbps 36 Mbps 6 Mbps
5.250 - 5.350 GHz (US) 1.7 mi/2.7 km 3.5 mi/5.6 km 8.5 mi/13.6 km
5.470 - 5.725 GHz (US& ETSI) 1.7 mi/2.7 km 3.4 mi/5.4 km 8.4 mi/13.4 km
5.725 - 5.850 GHz (US) 4.2 mi/6.7 km 10.2 mi/16.3 km 18.6 mi/29.8 km
5.85 - 6.08 GHz (Russia) 5.0 mi/8.0 km 10.0 mi/16.0 km 20.0 mi/32.0 km
