Industrial Power Corruptor Manual Rev 1.00
Data Acquisition
Internal Analog Input
Channels
13 internal voltage channels, 6 internal current channels, 3 protective earth current
monitoring channels.
External Analog Input
Channels
3 front panel ±600V (AC or DC) channels, 6 front panel ±100V ( AC or DC) channels.
Analog Input Viewing
Three front panel meters (including min. and max. values) can be selected to display any
data acquisition channel in real time. Alternatively, these channels can be monitored
using a connected PC and the software provided.
Resolution
15 bits equivalent per individual sample on 1000V / 1000A channels, 12 bits per individual
sample on other channels, 16 bit equivalent for average and RMS measurements
Accuracy
Guaranteed accuracy ±1,0% FS on voltage and current. Typical accuracy ±0,25% FS
(voltage and current), ±0,5% FS (power parameters), ±1,0% FS (harmonics), ±1°
(between any voltage and current channel)
Sampling Rate 0.8 KHz to 7.68 KHz
Phase lock
With Power Flow Analysis option, software phase-lock to user-selected voltage channel –
for precision harmonic and power flow calculations
Standard accessories included
CD-ROM Includes the latest software and diagnostics for the IPC, and the IPC User’s Manual
Power cord IEC-compatible power cord with North American plug
BNC caps Protective, military-style metallic caps for every front-panel BNC connector
Wire Adapters Set of 10 custom designed wire adapters required for connection to terminal blocks when
using smaller gauge wire.
Communication cable RJ-45 to DB-9 serial communication cable for connecting IPC to serial port on Windows
computer
Re-useable shipping crate
with custom padding
Custom, furniture-grade wooden shipping crate, with high-density fitted foam inserts and
external shock absorbing feet. Wing-nut fasteners for easy re-use. The IPC must always
be shipped in this case.
Options
Circuit Breaker Motor
Operator
Customized motor operator to operate circuit breaker handle from front panel switch
operation. Required for rack-mount installations. Recommended f or safety enhancement.
Power Flow Analysis
package
Software package for detailed power analysis and harmonics analysis. Includes
FlowScope graphing program for reviewing downloaded data, real-time Vector Scope,
real-time oscilloscope, real-time spectrum analyzer. Optimized for recording power
consumption of industrial processes, including SEMI E6.
Upgrade from
240V-25A to
480V-50A
Increases continuous current from 25 amps to 50 amps, and increases voltage rating from
240V to 480V. Requires brief return-to-factory for various internal upgrades.
Upgrade from
480V-50A to
480V-100A
Increases continuous current from 50 amps to 100 amps. Requires brief return-to-factory
for various internal upgrades.
Upgrade from
480V-100A to
480V-200A
Increases continuous current from 100 amps to 200 amps. Adds “combat mode” for
extended capabilities. Requires brief return-to-factory f or various internal upgrades,
including additional f ans.
Laptop controller
Strongly recommended. A Windows PC laptop, pre-loaded with all IPC software, and pre-
configured f or immediate use. Eliminates any questions about computer compatibility.
Additional Wire Adapters
Set of 10 custom designed wire adapters for connection to terminal blocks when using
smaller gauge wire.
Additional communication
cable
RJ-45 to DB-9 serial communication cable for connecting IPC to serial port on Windows
computer
Test lead kit Set of high and low-voltage connectors and cables for typical external data acquisition.
Replacement shipping crate
with custom padding
Custom, furniture-grade wooden shipping crate, with high-density fitted foam inserts and
external shock absorbing feet. Wing-nut fasteners for easy re-use. The IPC must always
be shipped in this case to reduce chance of damage from shock and vibration.
