ULTRA 3 INSTRUCTION MANUAL
114
The third parameter for each relay determines the Alarm ID for the relay
you wish to set.
P212, 222, 232 – Relay Alarm ID
When P211, 221, 231 = 4 (Loss of Echo) or 5 (Loss of Clock). This
parameter has no function and will not be displayed.
P211, 221, 231 = 1 (Level), 2 = Rate of Change or 3 (Temp)
This parameter defines which alarm type, or identification, the relay should
respond to, as follows:
Relay goes “ON” when the
value reaches the ON
setpoint and goes “OFF”
when the value reaches the
OFF setpoint.
P213, 223, 233 is ON
Setpoint; P214, 224, 234 is
OFF Setpoint
Relay goes “ON” when the
value rises to the ON
setpoint and goes “OFF”
when the value lowers to the
OFF setpoint.
ON>OFF Relay Setpoints
P213, 223, 233 and P214,
224, 234. Setpoints can be
set in any order as the unit
‘knows’ that you are setting
a high-level alarm.
Same as 2 = High, but different identifier
Relay goes “ON” when the
value lowers to the ON
setpoint and goes “OFF”
when the value rises to the
OFF setpoint.
ON<OFF Relay
Setpoints P213, 223, 233
and P214, 224, 234.
Setpoints can be set in any
order as the unit ‘knows’
that you are setting a low-
level alarm.
