PULSAR MEASUREMENT
115
OPTION
DESCRIPTION
SETPOINTS
5 = LoLo
Same as 4 = Lo, but
different identifier
6 = In bounds
Relay goes “ON” if value is
inside the zone between
the two setpoints.
Relay Setpoints, P213,
223, 233 and P214, 224,
234 can be set in any
order as the unit ‘knows’
that you are setting an
inbounds alarm.
7 = Out of bounds
Relay goes “ON” if value is
outside the zone between
the two setpoints.
Relay Setpoints P213,
223, 233 and P214, 224,
234 can be set in any
order as the unit ‘knows’
that you are setting an
out of bounds alarm.
The fourth parameter and the fifth parameter for each relay set the Alarm
“ON” and “OFF” points. For a high alarm, the “ON” is set higher than “OFF”.
For low alarm, then “ON” is set lower than “OFF”. See the appropriate alarm
ID, table (P212, 222, 232) for further information.
When P211, 221, 231 = 4 (L0ss of Echo) or 5 (Loss of Clock)
This parameter has no function and will not be displayed.
When P211, 221, 231 = 1 (Level), 2 (Rate of Change) or 3 (Temperature)
P213, P223, P233 - Relay Setpoint 1
Determines the “ON” or “OFF” point for the alarm according to the ID
selected.
P214, P224, P234 - Relay Setpoint 2
Determines the “ON” or “OFF” point for the alarm according to the ID
selected.
