ULTRA 3 INSTRUCTION MANUAL
62
Wait….
PARAMETER
DEFAULT
DESCRIPTION
P101 Transducer
2 = dB6
Type of transducer being used
P104
Measurement units
1 = Metres
Select units to be used for
programming measurement
information
P105
Empty Level
6m
Distance from the face of the transducer
to the material at the bottom of the
vessel
P106
Span
5.7m
Distance from the empty level (0% full)
to span (100% full).
For More Options Hit Enter
PARAMETER
DEFAULT
DESCRIPTION
P213 / P214
Relay 1 ON/OFF
setpoints
Factory preset as a % to
appropriate level according
to the span already
entered. See tables below
Either Alarm or Level control.
Depends on application.
P223 / P224
Relay 2 ON/OFF
setpoints
Factory preset as a % to
appropriate level according
to the span already
entered. See tables below
Either Alarm or Level control.
Depends on application.
P233 / P234
Relay 3 ON/OFF
setpoints
Factory preset as a % to
appropriate level according
to the span already
entered. See tables below
Either Alarm or Level control.
Depends on application.
P830 mA Out Range
2 = 4 to 20mA
Determines the mA output
range.
0 = Off, 1 = 0 to 20mA, 2 = 4
to 20mA, 3 = 20 to 0mA, 4 =
20 to 4mA.
P870 Fill damping
10m/min
Rate of maximum fill rate (set
above the actual fill rate of the
vessel).
P871 Empty
damping
10m/min
Rate of maximum empty rate
(set above the actual empty
rate of the vessel).
