Quick Setup Menu

The Quick Setup Menu detailing the questions you will be asked, when

setting up your Flow 3, via the Quick Setup is shown below.

PMD Type

0 = Off (No Calculation)

1 = Exponential

2 = BS3680 Flumes

3 = BS3680 Weirs

4 = Not Available

5 = Special

6 = Universal

For Each Alarm

1 = Set to Relay 1

2 = Set to Relay 2

3 = Set to Relay 3

Exponential

1 = Supp. Rect.

2 = Trapezoid

3 = Venturi

4 = Parshall

5 = Leopold L.

6 = V-Notch

7 = Other

8 = Contracted Rect.

BS3680 Flumes

1 = Rectangular

2 = Rect. + Hump

3 = U-Throat

4 = U-Throat + Hump

BS3680 Weirs

1 = Rectangular

2 = V-Notch 90

3 = V-Notch 53

8’

4 = V-Notch 28

4’

5 = Broad Crested

Special

= Palmer Bowlus

2 = H-Flume

3 = V-Notch Angle

Calculation

1 = Absolute

2 = Ratiometric

How Many Alarms

0 = No Alarms

1 = One Alarm

2 = Two Alarms

3 = Three Alarms

For Each Alarm

1 = High Alarm

2 = Low Alarm

3 = Hi Hi Alarm

4 = Lo Lo Alarm

5 = Loss of Echo

Quick Setup

Universal

1 = Linear flow

2 = Curved flow
