Pulsar ACCOLADE 2 LRF User Manual

Troubleshooting
☐
The device does not turn on
Possible cause
The Battery Pack is empty.
Solution
Charge the battery pack.
☐
The device does not operate on external power supply
Possible cause
USB cable is damaged.
Solution
Replace USB cable.
Possible cause
The external power supply is discharged.
Solution
Charge the external power supply.
☐
The image is blurry, with vertical stripes and uneven
background
Possible cause
Calibration is required.
Solution
Carry out calibration according to Microbolometer Calibrationsection.
☐
Black screen after calibration

Pulsar ACCOLADE 2 LRF Specifications

General

Objective Lens Diameter	50 mm
Detection Range	1800 m
Sensor Resolution	640x480 pixels
Display Type	AMOLED
Pixel Pitch	17 µm
Frame Rate	50 Hz
Laser Rangefinder Range	1000 m
Protection level	IPX7
Dimensions	164x130x64 mm
Waterproof	Yes
Fogproof	Yes
Weight	0.7 kg
Display Resolution	640x480 pixels
Operating Temperature	-25 … +50 °C
Battery Type	Li-Ion Battery Pack
