Replacement Parts and Accessories 8.
Table 2: Replacement Parts and Accessories
Description
Part number
Notes
Diaphragm – Silicone
AD09-2023
Old flat design
Diaphragm – Silicone
AD09-2029
New dimple design
Diaphragm - Kalrez
AD09-2026
Old flat design
Diaphragm - Kalrez
AD09-2028
New dimple design
Diaphragm - EPDM
AD09-2021
Old flat design
Diaphragm - FKM
AD09-2027
New dimple design
Nozzle Plate – 75µm, Ceramic
09-2303
Nozzle Plate – 100µm, Ceramic
09-2304
Nozzle Plate – 125µm, Ceramic
09-2305
Nozzle Plate – 200µm, Ceramic
09-2308
Replacement Insert –75µm, Ceramic
03-2303
Replacement Insert –100µm, Ceramic
03-2304
Replacement Insert –125µm, Ceramic
03-2305
Replacement Insert –200µm, Ceramic
03-2308
Nozzle Plate – 50µm, Carbide
09-2602
Nozzle Plate – 64µm, Carbide
09-26025
Nozzle Plate – 75µm, Carbide
09-2603
Nozzle Plate – 100µm, Carbide
09-2604
Nozzle Plate – 125µm, Carbide
09-2605
Nozzle Plate – 150µm, Carbide
09-2606
Nozzle Plate – 200µm, Carbide
09-2608
Nozzle Plate – 300µm, Carbide
09-2612
Nozzle Plate – 400µm, Carbide
09-2616
Replacement Insert –50µm, Carbide
03-2602
Replacement Insert –64µm, Carbide
03-26025
Replacement Insert –75µm, Carbide
03-2603
Replacement Insert –100µm, Carbide
03-2604
Replacement Insert –125µm, Carbide
03-2605
Replacement Insert –150µm, Carbide
03-2606
