PYE OLYMPIC M201 - Page 71

C Band
P8 Band
Inductors Contd.
Description
Coil Assemblies
Miscellaneous Items
Cavity
Cavity
Spring Contact
Scr. 2-56 unc x 3
1
16
PWB Assembly
Nut, hexagonal
Part No.

Remarks/Code/Band
AT32116/09

L1
AT32109/15 
L2
AT32116/10  L5,6
AT32116/11
 L8
AT32116/05 
L2
AT32116/06 
L3
AT32116/07

L4
AT32116/08

L7
AT32117/06 
L8
AT32118/01 
L1
AT32118/02
 L5,6
BT16823 
A,C,M2 Bands
BT16823/01
 E,P8 Bands
BT26983 
A Band
QJ08877/A
 19 off
AT12400/01
2 off
Sub-Modules
Thick-film module

FU00508 
TF1
Thick-film module

FU00509

TF2
Thick-film module

FU00510 
TF3
or alternatively:-
1st RF Amplifier assembly

AT27931
2nd RF Amplifier assembly

AT27932
Mixer assembly

AT27933
Coil Cores 
FCO2857 
L1—L8, A,M2,P8,C Band
FCO2899 
L1—L8, E Band
1st RF Amplifier Assembly AT27931 (1A)
Resistors
(S2)
100
±5%
0,125W
1k2
±5%
0,125W
4k7 ±5%
0,125W
metal oxide PL99757
 R3
metal oxide PL99770
 R2
metal oxide PL99777

R1
Capacitors
1n  ±10%

63V

cer. plate

PN99811

C1,3,4
4n7  ±10%

63V

cer. plate

PN99813

C2
Semiconductors
Transistor 2N4286

FU05821  TR 1
Transistor TIS88A 
FU08241  TR2
Inductors
Choke, 1µFl ±10%

FT05655 
L1
5.6
