1.1 Introduction
Overview
This document provides an overview of the hardware features of the chassis and
instructions on how to add and replace components for the server.
These guidelines are intended for trained service technicians.
System Features
The following is a list of the server features:
Table 1-1: Server System Features
Component
Description
Main Processor
• Type: Intel Cascade Lake P-8259CL, 24C, 2.5 GHz, 210W
• Count: 2
Mainboard
Cannonball16
System Memory
• Capacity & Speed: 384GB DDR4-2666
• DIMM Type: 32GB RDIMM DDR4-2666
• DIMM Count: 12
• Population per CPU Memory Channels: 1 DIMM per channel
GPU
• Type: Nvidia T4 low profile 70W PCIe Gen3, x16
mechanical, x8 electrical
• Count: 8
SSD
• Type: SATA SSD
• Quantity: 1
NVMe Drive
(2.5” SFF-8639)
• Type: 960GB, 1TB
• Quantity: 2
Add-on Cards
• Annapurna K2T-QB*1PCS
• Annapurna K2C-AB*1PCS
• Annapurna K2X-N*1PCS
System Fans
6 x fan modules
Power
Busbar
Chassis
2U
1-1
