Communication Protocol CubiScan 125 Command Set
CubiScan 125 Service Manual 60
The CubiScan 125 responds with a question mark NACK to any unrecognized command. For
example:
<STX><?><N><ETX><CR><LF>
When a NACK is sent by the CubiScan 125, the operation associated with that command is
aborted due to the error.
The CubiScan 125 recognizes the following commands from the command set for both a serial
and Ethernet connection.
Continuous Measure
This command toggles on or off a continuous measure mode. The readings transmitted are
Length, Height, Width, and Weight. Both dimensions and counts are transmitted.
Pos Len Description Type Range ASCII
Command Format
1 1 Start of Text Control (STX) 02h
2 1 Continuous Msr. Com. Alpha (C) 43h
31End of Text Control(ETX) 03h
4 1 Carriage Return Control (CR) 0Dh
5 1 Line Feed Control (LF) 0Ah
Acknowledge Format
1 1 Start of Text Control (STX) 02h
2 1 Measure Command Alpha (M) 4Dh
3 1 Acknowledge Alpha (A) 41h
41
CubiScan/Host
Originated
Alpha (C/H) 43h or 48h
56City Code Alpha
000000-ZZZZZ
Z
11 1 Comma Alpha (,) 2Ch
12 1 Length Identifier Alpha (L) 4C
13 5 Length Numeric 000.0-999.9*
18 1 Comma Alpha (,) 2Ch
19 1 Width Identifier Alpha (W) 57h
20 5 Width Numeric 000.0-999.9*
25 1 Comma Alpha (,) 2Ch
26 1 Height Identifier Alpha (H) 48h
27 5 Height Numeric 000.0-999.9*
32 1 Comma Alpha (,) 2Ch
To Next Page
