Communication Protocol CubiScan 125 Command Set
CubiScan 125 Service Manual 61
* This field may contain underscores, dashes, or overscores indicating an under, unstable, or over
error condition, respectively.
33 1 Dimension Unit Alpha (E/M) 45h or 4Dh
34 1 Comma Alpha (,) 2Ch
35 1 Weight Identifier Alpha (K) 4Bh
36 6 Weight Numeric 000.00-999.99*
42 1 Comma Alpha (,) 2Ch
43 1 Dim. Wgt. Identifier Alpha (D) 44h
44 6 Dim. Weight Numeric 000.00-999.99*
50 1 Comma Alpha (,) 2Ch
51 1 Wgt./Dim.Wgt Unit Alpha (E/M) 45h or 4Dh
52 1 Comma Alpha (,) 2Ch
53 1 Factor Identifier Alpha (F) 46h
54 4 Factor Numeric 0000-9999
58 1 Comma Alpha (,) 2Ch
59 1 Domestic/Int'l. Unit Alpha (D/I) 44h or 49h
60 1 End of Text Control (ETX) 03h
61 1 Carriage Return Control (CR) 0Dh
62 1 Line Feed Control (LF) 0Ah
Negative Acknowledge Format
1 1 Start of Text Control (STX) 02h
2 1 Measure Command Alpha (M) 4Dh
31Neg. Acknowledge Alpha (N) 4Eh
41
CubiScan/Host
Originated
Alpha (C/H) 43h or 48h
51
Corner Sensor / Measure
/ Zero Error
Alpha (C/M/Z)
43h or 4Dh
or 5Ah
61End of Text Control(ETX) 03h
7 1 Carriage Return Control (CR) 0Dh
8 1 Line Feed Control (LF) 0Ah
