Communication Protocol CubiScan 125 Command Set
CubiScan 125 Service Manual 62
CubiScan 100 Compatible Measure Mode
This data packet is received from the CubiScan 125 when a gate measurement is completed. It is
backwards compatible with the CubiScan 100.
Pos Len Description Type Range ASCII
Command Format
1 1 Start of Text Control (STX) 02h
2 1 Measure Command Alpha (M) 4Dh
31End of Text Control(ETX) 03h
4 1 Carriage Return Control (CR) 0Dh
51Line Feed Control(LF) 0Ah
Acknowledge Format
1 1 Start of Text Control (STX) 02h
2 1 Measure Command Alpha (M) 4Dh
3 1 Acknowledge Alpha (A) 41h
41
CubiScan/Host
Originated
Alpha (C/H) 43h or 48h
56City Code Alpha
000000-ZZZZZ
Z
11 1 Comma Alpha (,) 2Ch
12 1 Length Identifier Alpha (L) 4C
13 5 Length Numeric
000.0-999.9
1
18 1 Comma Alpha (,) 2Ch
19 1 Width Identifier Alpha (W) 57h
20 5 Width Numeric
000.0-999.9
1
25 1 Comma Alpha (,) 2Ch
26 1 Height Identifier Alpha (H) 48h
27 5 Height Numeric
000.0-999.9
1
32 1 Comma Alpha (,) 2Ch
33 1 Dimension Unit Alpha (E/M) 45h or 4Dh
34 1 Comma Alpha (,) 2Ch
35 1 Weight Identifier Alpha (K) 4Bh
36 6 Weight Numeric
000.00-999.99
42 1 Comma Alpha (,) 2Ch
43 1 Dim. Wgt. Identifier Alpha (D) 44h
