Communication Protocol CubiScan 125 Command Set
CubiScan 125 Service Manual 63
Dimension Calibration
This function is required when one of the sensors is replaced or moved, when a new control is
installed, or for routine calibration. This command causes the CubiScan 125 to reply with a
dimension calibration code each time it is issued. This command must be issued FIVE times to
complete sensor calibration. Dimension calibration codes are defined below.
44 6 Dim. Weight Numeric
000.00-999.99
50 1 Comma Alpha (,) 2Ch
51 1 Wgt./Dim.Wgt Unit Alpha (E/M) 45h or 4Dh
52 1 Comma Alpha (,) 2Ch
53 1 Factor Identifier Alpha (F) 46h
54 4 Factor Numeric 0000-9999
58 1 Comma Alpha (,) 2Ch
59 1 Domestic/Int'l. Unit Alpha (D/I) 44h or 49h
60 1 End of Text Control (ETX) 03h
61 1 Carriage Return Control (CR) 0Dh
62 1 Line Feed Control (LF) 0Ah
Negative Acknowledge Format
1 1 Start of Text Control (STX) 02h
2 1 Measure Command Alpha (M) 4Dh
31Neg. Acknowledge Alpha (N) 4Eh
41
CubiScan/Host
Originated
Alpha (C/H) 43h or 48h
51
Corner Sensor/Measure/
Zero Error
Alpha (C/M/Z) 43h or 4Dh
61End of Text Control(ETX) 03h
7 1 Carriage Return Control (CR) 0Dh
81Line Feed Control(LF) 0Ah
Pos Len Description Type Range ASCII
Command Format
1 1 Start of Text Control (STX) 02h
2 1 Dim.Calibration Alpha (D) 44h
31End of Text Control(ETX) 03h
4 1 Carriage Return Control (CR) 0Dh
51Line Feed Control(LF) 0Ah
Pos Len Description Type Range ASCII
