Quantronix CubiScan 125 Service Manual

Communication Protocol TCP/IP Communications Setup Command Set
CubiScan 125 Service Manual 82
Set Gateway Address
This command is used to set the network gateway address on the CubiScan 125. It can be the
address of a network server or router and is expressed in “dot” notation. Consult your network
administrator to obtain the network gateway address.
6 1 Carriage Return Control (CR) 0Dh
7 1 Line Feed Control (LF) 0Ah
Pos Len Description Type Range ASCII
Command Format
1 1 Start of Text Control (STX) 02h
2 1 Set Command Alpha (@) 40h
31
Gateway Address
Command
Alpha (G) 47h
4
7-15
or n
IP Address Alpha
(0.0.0.0) to
(255.255.255.255
)
4+n 1 End of Text Control (ETX) 03h
5+n 1 Carriage Return Control (CR) 0Dh
6+n 1 Line Feed Control (LF) 0Ah
Acknowledge Format
1 1 Start of Text Control (STX) 02h
2 1 Set Command Alpha (@) 40h
31
Gateway Address
Command
Alpha (G) 47h
41Acknowledge Alpha(A) 41h
51End of Text Control(ETX) 03h
6 1 Carriage Return Control (CR) 0Dh
7 1 Line Feed Control (LF) 0Ah
Negative Acknowledge Format
1 1 Start of Text Control (STX) 02h
2 1 Set Command Alpha (@) 40h
31
Gateway Address
Command
Alpha (G) 47h
4 1 Neg. Acknowledge Alpha (N) 4Eh
51End of Text Control(ETX) 03h
Pos Len Description Type Range ASCII
