Quantronix CubiScan 125 Service Manual

Communication Protocol TCP/IP Communications Setup Command Set
CubiScan 125 Service Manual 81
Read Subnet Address
This command is used to read the current subnet mask setting from the CubiScan 125.
Negative Acknowledge Format
1 1 Start of Text Control (STX) 02h
2 1 Set Command Alpha (@) 40h
3 1 Subnet Address Command Alpha (N) 4Eh
41Neg. Acknowledge Alpha(N) 4Eh
51End of Text Control(ETX) 03h
6 1 Carriage Return Control (CR) 0Dh
7 1 Line Feed Control (LF) 0Ah
Pos Len Description Type Range ASCII
Command Format
1 1 Start of Text Control (STX) 02h
2 1 Set Command Alpha (~) 7Eh
3 1 Subnet Address Command Alpha (N) 4Eh
41End of Text Control(ETX) 03h
5 1 Carriage Return Control (CR) 0Dh
6 1 Line Feed Control (LF) 0Ah
Acknowledge Format
1 1 Start of Text Control (STX) 02h
2 1 Set Command Alpha (~) 7Eh
3 1 Subnet Address Command Alpha (N) 4Eh
4 1 Acknowledge Alpha (A) 41h
5
7-15
or n
IP Address Alpha
(0.0.0.0) to
(255.255.255.255
)
5+n 1 End of Text Control (ETX) 03h
6+n 1 Carriage Return Control (CR) 0Dh
7+n 1 Line Feed Control (LF) 0Ah
Negative Acknowledge Format
1 1 Start of Text Control (STX) 02h
2 1 Set Command Alpha (~) 7Eh
3 1 Subnet Address Command Alpha (N) 4Eh
4 1 Neg. Acknowledge Alpha (N) 4Eh
51End of Text Control(ETX) 03h
Pos Len Description Type Range ASCII
