Quasar CP-3211 User Manual

Configuration and Operation
123
ICR Threshold
The ICR Threshold setting switches the sensitivity of the IR cut filter. Select one of the following
settings from the drop-down list:
 Low
 Mid
 High
Click Set to confirm the setting.
Zoom
Select Wide or Tele. Then drag the cursor on the Zoom bar to set the zoom level, which is displayed
in the window (x1..x18 on CP-3211-xxx or x1..x20 on CP-4221-xxx).
Focus
Select one of the following settings: Auto, Manual, Near, or Far.
Camera – Misc1 screen on the CP-4221-301
On the CP-4221-301, on the Camera-Misc1 page, you can set the following camera parameters:
 Sharpness
 Exposure compensation (ExpComp)
 Flip
 Digital zoom
 Speed by zoom
 Day/Night Function
 ICR Threshold
Figure 108: Camera – Misc1 Screen

Quasar CP-3211 Specifications

General

IR Distance	Up to 30 m
Night Vision	Yes
Resolution	1920x1080 (Full HD)
Minimum Illumination	0.01 Lux
Power Supply	DC 12V
