Quectel EG25-G - Layout Guidelines

LTE Module Series
EG25-G Hardware Design
EG25-G_Hardware_Design 62 / 100
@open sky
XTRA enabled
1.6
s
Accuracy
(GNSS)
CEP-50
Autonomous
@open sky
<4
m
1. Tracking sensitivity: the lowest GNSS signal value at the antenna port on which the module can keep
on positioning for 3 minutes.
2. Reacquisition sensitivity: the lowest GNSS signal value at the antenna port on which the module can
fix position again within 3 minutes after loss of lock.
3. Cold start sensitivity: the lowest GNSS signal value at the antenna port on which the module fixes
position within 3 minutes after executing cold start command.
4.3. Layout Guidelines
The following layout guidelines should be taken into account in customers’ designs.
 Maximize the distance among GNSS antenna, main antenna and Rx-diversity antenna.
 Digital circuits such as (U)SIM card, USB interface, camera module and display connector should be
kept away from the antennas.
 Use ground vias around the GNSS trace and sensitive analog signal traces to provide coplanar
isolation and protection.
 Keep 50Ω characteristic impedance for the ANT_GNSS trace.
Please refer to Chapter 5 for GNSS antenna reference design and antenna installation information.
NOTES
