Quectel EG25-G User Manual

LTE Module Series
EG25-G Hardware Design
EG25-G_Hardware_Design 74 / 100
6.4. Current Consumption
Table 34: EG25-G Current Consumption
Parameter
Description
Conditions
Typ.
Unit
I
VBAT
OFF state
Power down
15
uA
Sleep state
AT+CFUN=0 (USB disconnected)
1.8
mA
GSM @DRX=2 (USB disconnected)
2.9
mA
GSM @DRX=5 (USB disconnected)
2.4
mA
GSM @DRX=5 (USB suspended)
2.5
mA
GSM @DRX=9 (USB disconnected)
2.3
mA
DCS @DRX=2 (USB disconnected)
2.9
mA
DCS @DRX=5 (USB disconnected)
2.4
mA
DCS @DRX=5 (USB suspended)
2.5
mA
DCS @DRX=9 (USB disconnected)
2.3
mA
WCDMA @PF=64 (USB disconnected)
2.7
mA
WCDMA @PF=64 (USB suspended)
2.9
mA
WCDMA @PF=128 (USB disconnected)
2.3
mA
WCDMA @PF=256 (USB disconnected)
2.1
mA
WCDMA @ PF=512 (USB disconnected)
2.0
mA
LTE-FDD @PF=32 (USB disconnected)
4.3
mA
LTE-FDD @PF=64 (USB disconnected)
3.2
mA
LTE-FDD @PF=64 (USB suspended)
3.4
mA
LTE-FDD @PF=128 (USB disconnected)
2.7
mA
LTE-FDD @PF=256 (USB disconnected)
2.4
mA
LTE-TDD @PF=32 (USB disconnected)
4.6
mA
LTE-TDD @PF=64 (USB disconnected)
3.3
mA
