Quectel EG25-G - Page 76

LTE Module Series
EG25-G Hardware Design
EG25-G_Hardware_Design 75 / 100
LTE-TDD @PF=64 (USB suspended)
3.5
mA
LTE-TDD @PF=128 (USB disconnected)
2.7
mA
LTE-TDD @PF=256 (USB disconnected)
2.4
mA
Idle state
EGSM @DRX=5 (USB disconnected)
12
mA
EGSM @DRX=5 (USB connected)
22
mA
WCDMA @PF=64 (USB disconnected)
12
mA
WCDMA @PF=64 (USB connected)
24
mA
LTE-FDD @PF=64 (USB disconnected)
18
mA
LTE-FDD @PF=64 (USB connected)
29
mA
LTE-TDD @ PF=64 (USB disconnected)
18
mA
LTE-TDD @ PF=64 (USB connected)
29
mA
GPRS data
transfer
(GNSS OFF)
GSM900 4DL/1UL @32.5dBm
280
mA
GSM900 3DL/2UL @32dBm
530
mA
GSM900 2DL/3UL @30dBm
601
mA
GSM900 1DL/4UL @29dBm
658
mA
GSM850 4DL/1UL @32.5dBm
285
mA
GSM850 3DL/2UL @32dBm
532
mA
GSM850 2DL/3UL @30dBm
610
mA
GSM850 1DL/4UL @29dBm
680
mA
DCS1800 4DL/1UL @29.5dBm
162
mA
DCS1800 3DL/2UL @29dBm
271
mA
DCS1800 2DL/3UL @27dBm
365
mA
DCS1800 1DL/4UL @26dBm
460
mA
PCS1900 4DL/1UL @29.5dBm
170
mA
PCS1900 3DL/2UL @29dBm
310
mA
PCS1900 2DL/3UL @27dBm
400
mA
PCS1900 1DL/4UL @26dBm
480
mA
