Quectel EG25-G - Page 77

LTE Module Series
EG25-G Hardware Design
EG25-G_Hardware_Design 76 / 100
EDGE data
transfer
(GNSS OFF)
GSM900 4DL/1UL @27dBm
180
mA
GSM900 3DL/2UL @26dBm
340
mA
GSM900 2DL/3UL @24dBm
460
mA
GSM900 1DL/4UL @23dBm
576
mA
GSM850 4DL/1UL @27dBm
190
mA
GSM850 3DL/2UL @26dBm
350-
mA
GSM850 2DL/3UL @24dBm
465
mA
GSM850 1DL/4UL @23dBm
573
mA
DCS1800 4DL/1UL @26dBm
200
mA
DCS1800 3DL/2UL @25dBm
371
mA
DCS1800 2DL/3UL @23dBm
522
mA
DCS1800 1DL/4UL @22dBm
670
mA
PCS1900 4DL/1UL @26dBm
210
mA
PCS1900 3DL/2UL @25dBm
370
mA
PCS1900 2DL/3UL @23dBm
525
mA
PCS1900 1DL/4UL @22dBm
670
mA
WCDMA data
transfer
(GNSS OFF)
WCDMA B1 HSDPA @21dBm
546
mA
WCDMA B1 HSUPA @20.5dBm
530
mA
WCDMA B2 HSDPA @21dBm
580
mA
WCDMA B2 HSUPA @20.5dBm
560
mA
WCDMA B4 HSDPA @21dBm
565
mA
WCDMA B4 HSUPA @20.5dBm
540
mA
WCDMA B5 HSDPA @21dBm
530
mA
WCDMA B5 HSUPA @20.5dBm
505
mA
WCDMA B6 HSDPA @21dBm
532
mA
WCDMA B6 HSUPA @20.5dBm
510
mA
WCDMA B8 HSDPA @21dBm
550
mA
