o Windshield Wiper: Only available on output channel 19 (pin A17). Allows a direct method to
be utilized for windshield wiper motor/parking operation. When a direct method is used, a
reference channel named Wiper Brake Control Channel becomes selectable. An input channel
must be selected in order to Park the wipers in the correct location. This is the channel that will
be the input referenced for the Park position. See SmartWire Installation manual for further
details.
Output Number: Designates the output channel number (not actual pin/connection number)
Missing VNET Message Logic: Designates the condition for any of the Setpoint Control Channels,
used in this particular channels operation, should they become inactive/missing on the VNET CAN bus.
Example: A water temp sensor is used in the logic to turn on/off this output to control a fan. When the
water temp goes above 180F, the condition for this would go True, therefore making the fan output
condition True and the fan would turn on. If by chance, this water temp sensor module becomes
inactive/unplugged at any time then the “Missing VNet Message Logic” setting will be referenced for
this channel. In a case where the water temp sensor module becomes inactive/unplugged, if set to
“Condition True” this would turn the fan on. If set to “Condition False” the fan would never turn and
overheating will occur. Default=Condition False
NOTE: For critical controlled items, a range check should be performed on any input channel
(sensor) associated with the output. This range should be taken into consideration when
programmed into the True/False settings, to ensure the output will be in a non-problematic
state should the input channel (sensor) fail or go outside its operating range.
Fuse Current: Fuse value, this is the max current that is allowed before fuse is blown (output off).
Higher numbers than the channel output are possible only for surge (momentary) times. Default=20 on
20 amp Type, 15 on 10 amp Type.
Logger Sample Rate: Logging sample rate of this channels when used with a Racepak data logger.
Default=off
Current Graph Min: Minimum graph scaling for the Current (Amp) Y axis of this channel. Pertains
only to logging of this channel. Default=0
Current Graph Max: Maximum graph scaling for the Current (Amp) Y axis of this channel. Pertains
only to logging of this channel. Default=35
Volts Graph Min: Minimum graph scaling for the Volts Y axis of this channel. Pertains only to logging
of this channel. Default=0
