Racepak
30402 Esperanza, Rancho Santa Margarita, CA 92688 USA
Phone: 949-709-5555 Fax: 949-709-5556 www.racepak.com
16
• Volts Graph Max: Maximum graph scaling for the Volts Y axis of this channel. Pertains only to
logging of this channel. Default=35
• Fuse Reset Delay: Number of seconds between blown fuse and resetting of the fuse. Default=2
• Max Fuse Retries: Number of times the system will try to reset a blown fuse. Default=100VNet
Update Rate: Sample rate of the broadcast of this channel out to other devices/channels on the V-Net.
Default=10
• Switch Bus Update Rate: Sample rate of the broadcast between this channel and items connected to the
switch port on the SmartWire unit. Default=10
• On Delay Time: Once the condition is true, this is the amount of delay before output becomes active.
Default=0
• Off Delay Time: Once a true condition goes false, this is the amount of delay before the output becomes
inactive. Only shown when Output Function set to Constant On or Flash Default=0
• Flash On Time: Once the condition is true and the On Delay Time is finished, this is the amount of time
the output will be active. Once this time is finished, the Flash Off Time becomes active. Only shown
when Output Function set to Flash Default=0.5
• Flash Off Time: Once the Flash On Time is finished, this is the amount of time the output will be
inactive. Once this time is finished, the Flash On Time becomes active. Only shown when Output
Function set to Flash Default=0.5
• Pulse Time: Once the condition is true and the On Delay Time is finished, this is the amount of time the
output will be active. Only shown when Output Function set to Pulse
Buttons (lower right of window):
• On Condition: Shows the On/Off Conditions logic window for this channel
• Start Channel Live Data: Starts the Real-Time window for this channel
• Send Configuration: Sends the windows current values of this channel to the SmartWire
• Read Configuration: Reads the values from the SmartWire and populates the window with the
currently programmed values of this channel.
