15
Revised 4-21-10
Part# SH-2XLRMF StudioHub+ Dual XLR Male/Female Panel
(856) 467-8000
•
Fax (856) 467-3044
•
www.studiohub.com
RJ45-1 RJ45-2
Female XLR Male XLR
Install JU1 to connect XLR(s)
pin 1 to chassis ground
JU2
Install to connect XLR(s) pin 1
to StudioHub+ RJ45 shield
JU2
Install to connect XLR(s) pin 1
to StudioHub+ RJ45
power ground (RJ-45 pin 4)
2
1
3
8
7
6
5
4
3
2
1
Female
XLR
RJ-45 #1
8
7
6
5
4
3
2
1
2
1
3
Male
XLR
RJ-45 #2
CHASSIS
GROUND
JU1
JU2
JU1
JU2
CHASSIS
GROUND
CHASSIS
GROUND
CHASSIS
GROUND
