ASSEMBLY 12013

FOUR SELECT BOARD

STUDIOHUB+

J2J1

SW1

JU8JU7JU6JU5JU4JU3JU2JU1

(Obsolete Part) SH-4SW StudioHub+ 4 Source Switcher Panel

(856) 467-8000

•

Fax (856) 467-3044

•

www.studiohub.com

Stereo StudioHub+ RJ45

Jumpers JU1-JU8 tie +15volt and –15volt

from input RJ45(s) to the output RJ45 J5

JU1 –15volts input 1

JU2 +15volts input 1

JU3 –15volts input 2

JU4 +15volts input 2

JU5 –15volts input 3

JU6 +15volts input 3

JU7 –15volts input 4

JU8 +15volts input 4

1 2 3 4

input 1 input 2 input 3 input 4 output

Input selects

Note:

This part obsolete as of

September 2012.

Replaced by active model

SH-4SWA
