ASSEMBLY 12044B

STUDIOHUB+

M XLR TO RJ45

JU4JU3

JU1

JU2

Part # SH-1XLRM StudioHub+ Single XLR Male Panel

(856) 467-8000

•

Fax (856) 467-3044

•

www.studiohub.com

JU1

Install to connect XLR pins to chassis ground

JU2

Install to connect XLR pins to

power ground

Install to connect XLR pin 1 to

shield ground

JU3, JU4

Install for left and right in parallel

Remove for left only

XLR
