Preface
1.1 Before you begin
Thank you for your interest in Radiodetection’s Pipeline
Current Mapping System.
Please read this user manual in its entirety before
attempting to use the PCM system as it contains many
important safety notices and warnings.
Radiodetection products, including this manual, are
under continuous development. The information
contained within is accurate at the time of publication;
however the PCMx Locator, PCM Transmitter, this
manual and all its contents are subject to change.
Radiodetection Limited reserves the right to modify the
product without notice and some product changes may
have taken place after this user manual was published.
Contact your local Radiodetection dealer or visit
www.radiodetection.com for the latest information about
the Pipeline Current Mapping product family, including
this manual.
1.2 Important notice
General
The performance of any cable and pipe locator may be
affected when used in close proximity to ferrous materials
such as manhole covers, steel-toe boots, mobile phones
and nearby vehicles. Keep a distance of 1 or 2 m from
these objects when taking critical measurements such as
depth and current readings.
This instrument, or family of instruments, will not be
permanently damaged by reasonable electrostatic
discharge and has been tested in accordance with BS
EN61326-1. However, in extreme cases temporary
malfunction may occur. If this happens, switch off, wait
and switch on again. If the instrument still malfunctions,
disconnect the batteries for a few seconds.
Safety
WARNING: Failure to comply with safety warnings
can cause serious injury or death.
CAUTION: Failure to comply with safety cautions can
result in damage to equipment or property.
This equipment shall be used only by qualified and
trained personnel, and only after fully reading this
Operation Manual.
WARNING: Direct connection to live conductors is
POTENTIALLY LETHAL. Direct connections
to live conductors should only be attempted
by fully qualified personnel using the relevant
products that allow connections to energized
lines.
WARNING: Reduce audio level before using
headphones to avoid damaging your hearing.
WARNING: This equipment is NOT approved for use
in areas where hazardous gases may be
present.
CAUTION: The battery cover, the accessory cover and
the headphone cover protect the locator’s sockets from
debris and water ingress. If they get damaged or lost,
contact Radiodetection or your local service
representative for a replacement one.
Batteries
WARNING: Batteries can get hot after prolonged use
at full output power. Take care while replacing
or handling batteries.
WARNING: Do not tamper with, or attempt to
disassemble the battery packs.
CAUTION: If battery failure is suspected return the entire
unit to an authorized repair center for investigation and
repair. Local, national or IATA transport regulations may
restrict the shipment of faulty batteries. Check with your
courier for restrictions and best practice guidelines. Your
local Radiodetection representative will be able to direct
you to our authorized repair centers.
WARNING: Exposing the battery to a high
temperature above 60°C (140°F) may activate
safety systems and cause a permanent
battery failure.
