© 2021 Radiodetection Ltd 6
Tx-25 and
Tx-150 PCM Transmitter
The Tx-25 PCM is a 1A transmitter and aimed at users
who want a fully portable system for use where no
external power supply is available.
The Tx-150 PCM is a powerful 3A transmitter, capable of
sending detectable signals up to 30km (20 miles) from
the connection point.
The Tx-25 & Tx-150 transmitters are housed in rugged
waterproof cases. To open the transmitter, unsnap the
clips on either side of the handle. In certain situations, the
air pressure within the case may need to be equalized by
unscrewing the small knob located near the handle.
3.1
Transmitter control panels
Fig. 3.1: Tx-150 PCM Transmitter
