13
IQ Network Communication Cartridge
CM Port
IQ Port
RS-232 External Modem Cable (Beige)
RJ-11 Phone Cord (Silver)
RJ-45 Ethernet Cable (Green)
GPRS Cellular Internal Antenna (Gold)
WiFi Internal Antenna (Gold)
IQ Network
Communication
Cartridge
(IQ-NCC)
CM Y-Cable (black)
CM Straight Cable (black)
Align Arrows
on Cable and
Housing for
Correct Fitting
CM Port Cables
IQ Port Cables
Figure 4 - Installation/ Cable Options
