ISCOM2600 (B) Series Product Description
1 Overview
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
10
Model
Description
ISCOM2600-
28X-PWR-
AC_DC

Provide twenty-four 10/100/1000 Mbit/s RJ45 downlink optical
interfaces.

Provide four 10 Gbit/s SFP+ uplink interfaces (also supporting 1000
Mbit/s SFP).

Provide 1 SNMP interface for out-of-band network management.

Provide 1 RJ45 Console interface.

Provide 1 USB interface.

Support the 220 VDC power supply and -48 VDC power supply.

The twenty-four downlink interfaces support PoE and can supply
power to remote PDs. They support IEEE802.3af and IEEE802.3at.
ISCOM2600-
28X-PWH-
AC/D

Provide twenty-four 10/100/1000 Mbit/s RJ45 downlink optical
interfaces.

Provide four 10 Gbit/s SFP+ uplink interfaces (also supporting 1000
Mbit/s SFP).

Provide 1 SNMP interface for out-of-band network management.

Provide 1 RJ45 Console interface.

Provide 1 USB interface.

Support dual 220 VAC power supplies.

The twenty-four downlink interfaces support PoE and can supply
power to remote PDs. Downlink electrical interfaces 1–8 support
IEEE802.3af, IEEE802.3at, and IEEE802.3bt. Downlink electrical
interfaces 9–24 support IEEE802.3af and IEEE802.3at.
ISCOM2600-
28X-PWH-
DC/D

Provide twenty-four 10/100/1000 Mbit/s RJ45 downlink optical
interfaces.

Provide four 10 Gbit/s SFP+ uplink interfaces (also supporting 1000
Mbit/s SFP).

Provide 1 SNMP interface for out-of-band network management.

Provide 1 RJ45 Console interface.

Provide 1 USB interface.

Support dual 220 VDC power supplies.

The twenty-four downlink interfaces support PoE and can supply
power to remote PDs. Downlink electrical interfaces 1–8 support
IEEE802.3af, IEEE802.3at, and IEEE802.3bt. Downlink electrical
interfaces 9–24 support IEEE802.3af and IEEE802.3at.
ISCOM2600-
28X-PWH-
AC/S

Provide twenty-four 10/100/1000 Mbit/s RJ45 downlink optical
interfaces.

Provide four 10 Gbit/s SFP+ uplink interfaces (also supporting 1000
Mbit/s SFP).

Provide 1 SNMP interface for out-of-band network management.

Provide 1 RJ45 Console interface.

Provide 1 USB interface.

Support single 220 VAC power supply.

The twenty-four downlink interfaces support PoE and can supply
power to remote PDs. Downlink electrical interfaces 1–8 support
IEEE802.3af, IEEE802.3at, and IEEE802.3bt. Downlink electrical
interfaces 9–24 support IEEE802.3af and IEEE802.3at.
