Local Control (Local Mode) R&S XU 4200
3.51 6166.5368.02.01
TX CBIT STATUS
Meaning
of entries
T X C B
I
T
S
t
a
t
u
s
1 0 2 N
O
G
O
E
2 0 2 P
S
U
F
A
N
E
2 0 3 P
S
U
T
E
M
P
W
3 1 7 P
A
T
E
M
P
W
3 3 6 L
O
C
A
L
M
O
D
E
W
Fig. 3.38 TX CBIT STATUS.
Display text (error code) Status Description
TX CBIT Status – Menu name
102 NOGO ERROR General fault in the radio; at least one CBIT error
message is active
202 PSU FAN ERROR No rotation of the power supply unit fan
203 PSU TEMP WARNING Temperature exceeded on the PSU Board
317 PA TEMP WARNING Temperature exceeded on the PA board
336 LOCAL MODE WARNING If necessary, entering the local mode can be stored as
a CBIT warning and event. However, this function must
be first configured via a service PC. Unauthorized local
control can then be detected and forwarded to the
remote control system as a warning.
Note: See chapter 4.2 Troubleshooting for detailed CBIT event
descriptions.
