R&S 4200 Series - Setting Parameters; Fig. 3.18 Submenu

Local Control (Local Mode) R&S XU 4200
3.37 6166.5368.02.01
5. Press the ENTER key.
The submenu will be opened and the radio status displayed.
T X C B I T S t a t u s
1 0 2 N O G O E
2 0 2 P S U F A N E
2 0 3 P S U T E M P W
3 1 7 P A T E M P W
3 3 6 L O C A L M O D E W
Fig. 3.18 Submenu.
Note: The scroll bar on the right indicates that you can display further
entries by using the  or  cursor keys.
Exit
submenu
6. Press the ESC key.
The submenu will be exited (returned to parent menu).
3.4.6 Setting Parameters
Note: All parameter changes can be set only in the local mode. Press the
local button to activate the local mode. The statement LOC appears in the
LCD display above on the right in each menu.
Various methods
possible
0.
You can set parameters in various ways:
 Directly selecting of radio functions
 Toggling a setting
 Selecting settings
 Entering numeric parameters
The keypad can be used to select and enter radio parameters.
Direct selec tion of r adio functio ns\Direct se lection of r adio functio ns "Radio".doc
