R&S XU 4200 Troubleshooting
6166.5368.02.01 4.4
4.2 Troubleshooting
Troubleshoo ting\Troubles hooting "Radio".doc
CBIT events
If an event occurs on the radio, it will be stored in the event log of the radio.
The event log can be read out via LAN interface or using the Service and
Maintenance Tool R&S ZS4200. The following chapters give an overview
about all the possible CBIT events.
Note: In most cases of error, the transceiver will need to be transferred to
the nearest service.
Column Description
Code Code is the unique number for this kind of event.
Message Message is the designation of this event.
Level Level is a ranking of this event (W = warning; E = error).
Warnings and errors will be logged into CBIT status list.
Errors and NOGO warnings additionally cause NOGO
(LED GO not illuminated, error code 102).
Config Config states the configurability of each event:
W = event can be configured as warning,
N = event can be configured to cause NOGO.
Notes Notes describes the reasons and if necessary the
reaction of the radio when the event occurs.
Description of
columns
Action Action describes what the user can do to eliminate the
cause of the event.
CBIT events\CBIT events "Radio".doc
CBIT events\\CBIT events Transmitter STANDARD.doc
4.2.1 TX CBIT Events
Code Message Level Config Note Action
0101 INACTIVE WARNING W W Radio was switched to
the inactive mode, e.g.
via the *OFF contact on
the rear panel or by
software command or
locally on the radio (see
chapter 3.4.7.2).
Not
e: If the radio
swit
ches into INACTIVE
mode, all active VoIP
connections will be
terminated and new
VoIP connection
requests will be
rejected.
Check the VOP LED (see
chapter 4.1.2).
Che
ck the hardware
input *OFF on
connector
X5.7.
Check software settings.
