R&S XU 4200 Local Control (Local Mode)
6166.5368.02.01 3.38
3.4.6.1 Direct Selection of Radio Functions
Introduction
After you select a menu, various radio functions will be displayed. Radio
functions are carried out directly after you press the ENTER key.
For example:
Power up the
transmitter with test
modulation
1. Press the MENU key.
2. Using the or cursor keys, select the MEASUREMENT submenu.
M
e a s
u
r
e
m
e
n
t
3. Press the ENTER key.
The submenu will be opened.
4. Using the
or cursor keys, select the TX PARAMETER submenu.
T X P
a
r
a
m
e
t
e
r
5. Press the ENTER key.
The submenu will be opened.
T X P
a
r
a
m
e
t
e
r
L O
C
P W R
0
W
5
0
4
9
M O D
0
%
1
0
0
7
2
S W R
1
2
5
1
.
3
T e s t P T T
T
e
s
t T
O
N E
6. Using the or cursor keys, select the TEST TONE function.
T e s t P T T
T
e
s
t T
O
N E
Fig. 3.19 Direct selection of radio functions.
7. Press the ENTER key.
The test will be started. The transmitter will be powered up with a 1 kHz
test tone and the configured AM modulation.
Note: TX transmission is switched on as long as the ENTER key is
pressed or until the timeout PTT timer switches off the transmission.
