R&S SMW200A User Manual

Instrument Tour
R&S
®
SMW200A
44Getting Started 1412.9220.02 ─ 21
Table 5-11: Overview of the DIG I/Q interfaces and the required options
Location Designation Required option
CODER boards CODER 1/2 In R&S SMW-B10, standard baseband generator
R&S SMW-B9, wideband baseband generator,
if "System Config > Mode = Advanced"
FADER boards FADER 1/2/3/4
In/Out
R&S SMW-B14, fading simulator
BBMM board BBMM 1/2 Out R&S SMW-B13/-B13T and
R&S SMW-K18, digital baseband output
R&S SMW-B13XT, if "System Config > Mode =
Advanced"
A dedicated LED indicates the connector status:
●
Green: an input connector
●
Yellow: an output connector
●
No light: the connector is not active
EXT x 1/2
Input for external analog modulation signals.
Any of the two inputs can be used for path A and path B.
LF OUT x
Option: R&S SMW-B13/-B13T
Output for internal LF generator signal.
Note: The output of the internal LF signal and the analog I/Q signal use the same
physical connectors.
These signals cannot be output at the same time.
See also data sheet and user manual, section "Analog Modulation".
I/Q, I/Q Bar
Direct (single-ended) or differential output for the analog I/Q signal.
The number of connectors depends on the installed baseband options:
●
Standard baseband (R&S SMW-B10 and R&S SMW-B13T)
Two single-ended analog and two differential outputs.
Output of differential signal requires option R&S SMW-K16.
●
Wideband baseband (R&S SMW-B9 and R&S SMW-B13XT)
Two single-ended analog or one differential output. Differential and single-
ended signals cannot be output at the same time.
Output of differential signal requires option R&S SMW-K17.
Rear Panel Tour
