R&S SMW200A User Manual

Instrument Tour
R&S
®
SMW200A
43Getting Started 1412.9220.02 ─ 21
T/M/C
Multipurpose input/output trigger/marker/clock connectors.
The number of connectors depend on the installed baseband options:
●
Standard baseband generator (R&S SMW-B10):
One T/M/C and two T/M connectors per board.
●
Wideband baseband generator (R&S SMW-B9):
One T/M/C and one T/M connectors per board
The input/output signal has to be defined. The Table 5-9 lists the configuration of
the local connectors in the default instrument state.
Table 5-9: Default configuration of the T/M/C connectors (standard baseband)
T/M/C connector
(Standard baseband)
Direction Default assigned
signal
Remark
1, 4 Output Clock Local clock signal for the par-
ticular baseband
2, 5 Input Trigger Local trigger signal for the
particular baseband
3, 6 Output Marker 3 Marker output signal from the
particular baseband
Table 5-10: Default configuration of the T/M/C connectors (wideband baseband)
T/M/C connector Direction Default assigned signal
1 Output Symbol clock
2 Input External serial data
A dedicated LED indicates the connector status:
●
Green: an input connector
●
Yellow: an output connector
●
No light: the connector is not active
See also chapters "Data, Clock and Control Signals and Sources in the Base-
band" and "Local and Global Connectors" in the user manual.
DIG I/Q
Connectors for the input/output of a digital I/Q signal from and to a
Rohde & Schwarz instrument, like a signal generator, signal analyzer, the R&S
EX-IQ-BOX, or the R&S
®
CMW500.
The interfaces require the options listed in Table 5-11 (for details see the data
sheet).
Rear Panel Tour
