55
Compass
To navigate the menu follow the instructions in the picture on the left
Compass resolution: 1°
Compass accuracy: +/-1°
Press D
Button to set the current Route
Press and hold B to increase the reactivity of the compass
When in “Compass” mode the iX3M 2 shows:
DIRECTION (on the top centre): the current direction expressed in
degrees (°)
GRAPHIC COMPASS (on the centre): graphic compass with route
indications.
Direction in route (+/- 5° in comparison with the one set with D)
It indicates the direction to follow to find the route you have set
Reciprocal direction (+/- 5° in comparison with the set reciprocal route )
DIR: Current set route
REC: Reciprocal of the set route
Helpful tip:
The RATIO iX3M 2’s 3D compass is compensated by 2 accelerometers. The iX3M 2 can compensate your arm’s
grade automatically up to an angle of 85° from the horizontal position.
ATTENTION:
The Compass works correctly
only if its calibration has been
done correctly.
See paragraph: COMPASS
12:00
100%
N
NENE
....
0°
DIR REC
0°
180°
a D
eXit roUte
