Spreading operation with the QUANTRON-A control unit
97
5
Switch-off distance (m)
Switch-off distance refers to the switch-off distance (figure 5.7
[B]) relating to
the field border (figure 5.7
[C]). At this position in the field, the metering slides
start to close.
Figure 5.7: Switch-off distance (relating to field border)
[B] Switch-off distance
[C] Field border
If the switch-off position in the field is to be changed, the switch-off distance has
to be adjusted.
 A lower distance value means that the switch-off position is closer to the field
border.
 A greater value means that the switch off position is closer to the centre of the
field.
If you wish to turn beyond the headland track, enter a greater distance in Switch-
off distance.
Here, the adjustment must be as low as possible so that the metering slides close
as soon as the tractor enters the headland track. An adjustment of the switch off
distance may lead to an insufficient fertilisation in the area of the switch off posi-
tion in the field.
B
C
