Then push Update Network to add the device to the list.
Removal of Device - If you remove a device or RTD from the network, using the Update Network button will not
remove the device from memory. You must use the “Remove Device” button found in the Network|Remove window.
The table below shows the available device addresses for Relay Outputs and RTDs. If module(s) are installed either in the field or in
the NGC-30 panel, they must NOT share the same address as the NGC-30-CRM/CRMS.
.
Switch Setting
NGC-30-CRM/-CRMS Relay Output/RTD 1–99 1–99
PLI RTD 1–99 1–99
NGC-20 Relay Output/RTD Via Software 1-247
RMM-DI Digital Input 1-247 1-247
Elexant 5010i Relay Output/RTD Via Software 1-247
RMM2 RTD 0 32
RMM2 RTD 1 33
RMM2 RTD 2 34
RMM2 RTD 3 35
RMM2 RTD 4 36
RMM2 RTD 5 37
RMM2 RTD 6 38
RMM2 RTD 7 39
RMM2 RTD 8 40
RMM2 RTD 9 41
RMM2 RTD A 42
RMM2 RTD B 43
RMM2 RTD C 44
RMM2 RTD D 45
RMM2 RTD E 46
RMM2 RTD F 47
