Qualified nVent Personnel Only. It is recommended that only nVent personnel exit the NGC-UIT3 program.
With a USB drive, you can back up the current configuration of a UIT3. All of the configuration settings will be saved in an XML format
so that it is easily read and edited on a computer. This includes the following:
• Circuit Database
- The currently configured circuits on the UIT3
• Events Database
- The last 2000 events that have occurred.
• Network List
- All of the devices that appear in the Network|Device screen
• Preferences
- The user preferences, which include parameters such as Temperature Units, Language and Screen Timeout
Insert a USB drive into the UIT3 and wait for the USB Service Panel to appear on the screen.
Fig. A.1 The USB service panel
