Chapter 2: System Integration 9
2.2 Compatibility
Radar Scanners
CAUTION: Radar Scanners, Cables & Installation
Information on radar scanners, cables and their installation contained in
this handbook supersedes that contained in the Pathfinder Radar
Scanner Handbook, Document No. 81154_6, dated 11th March 2002.
To achieve full radar compatibility with your E-Series Display, your Raymarine radar
scanner may require upgrading. Please check the list below to see if this upgrade is
required.
The scanner serial number can be found on a label attached to the scanner casing:
The Open Array system will also require a split pedestal cable.
If your radar scanner requires upgrading, please contact your local Raymarine dealer
for full information.
Digital Sounder Module
Important:
In order for your Digital Sounder Module (DSM) to be compatible with your E-Series
display, you will need a DSM300 (Part no. E63049).
Scanner type Serial Number Compatibility
2Kw Radome 1220000 and below Not compatible
1220001 - 0530157 Upgrade required
0530158 and above Fully compatible
4Kw Radome 1220000 and below Not compatible
1222001 - 0530246 Upgrade required
0530247 and above Fully compatible
4Kw Open Array 1030000 and below Not compatible
1030001 - 1230143 Upgrade required
1230144 and above Fully compatible
10Kw Open Array 0430000 and below Not compatible
0430001 and above Fully compatible
